Summary

Dimension(mm):

12000×2500×3900MM

Model Number:

HB37K

Place of origin:

China

Brand Name:

XCMG

Certification:

CE/ISO9001

Specifications

Weight:

24500kg

Moving Type:

Wheel

Condition:

New

Theoretical output:

130cbm/h

Max.speed:

Power:

279000W

Max. horizontal conveying distance:

32m

Packaging & Shipping

Delivery Lead Time:

7 days for ready goods

Minimum Order:

Supply Ability:

10,000 Set/ Sets per Month

Total Quantity In Stock:

Over 5000

Delivery Port:

Any Port In China

Details

Description		Unit	Parameter value
Outline dimension		mm	12000×2500×3900
Overall weight		kg	24500
Chassis	Model		ZZ5307N4647C
	Max. speed	km/h	90
	Max. grade-ability	%	40
	Wheelbase	mm	4600+1350
	Tire		11.00R22.5
Engine	Model		WD615.96
	Max. power	kW	279
	Max. torque	N·m/(r/min)	1590/1100~1600
	Displacement	L	9.276
	Emission standard		Eruo III
Pumping system	Theoretical output	m³/h	130
	Concrete pumping pressure	MPa	8
	Theoretical pumping times	Time/min	24~27
	Delivery cylinder diameter ×stroke	mm	φ230×2000
	Max. diameter of pumping concrete	mm	40
	Filling height	mm	1580
	Concrete slump range	cm	8~23
Placing boom	Reach height	m	29.6
	Reach depth	m	18
	Slewingradius	m	36.5
	Slewing angle	°	±270
	Unfolding angle of the 1st section	°	90
	Unfolding angle of the 2nd section	°	180
	Unfolding angle of the 3rd section	°	245
	Unfolding angle of the 4th section	°	235
Stabilizer span	Longitudinal span of stabilizer	mm	6421
	Transverse span of front stabilizer	mm	5430
	Transverse span of rear stabilizer	mm	7381
Others	Lubrication method		Automatic lubrication
	Control method		Manual/remote control
	Volume of water box	L	600
