Summary

Drive Type:

Internal Combustion Drive

Bucket Capacity:

0.5~1.0m³

Place of origin:

China

HS Code:

8429590000

Specifications

Max. traction:

122 KN

Swing speed:

13 rpm

Maximum digging radius:

8335 mm

Ground maximum digging depth:

5288 mm

Packaging & Shipping

Delivery Lead Time:

7 days for ready goods

Minimum Order:

Supply Ability:

10,000 Set/ Sets per Month

Total Quantity In Stock:

Over 5000

Delivery Port:

Any Port In China

Details

Dimensions	Operating weight	Kg	13890
	Rated bucket capacity	m³	0.6
	Overall length	mm	7762
	Overall width(600mm track shoe)	mm	2510
	Overall height	mm	2983
	Trunable width	mm	2510
	Cabin height	mm	2825
	Groundclearance of counterweight	mm	915
	Engine cover height	mm	2243
	Min. ground clearance	mm	416
	Tail length	mm	3205
	Turning radius of turnable	mm	2306
	Wheel base of track shoe	mm	4030
	Chassis length	mm	3010
	Chassis width	mm	2490
	Track shoe gauge	mm	1990
	Standard track shoe width	mm	500
Performance	Max. traction	KN	122
	Travelling speed (H/L)	Km/hr	5.9/3.4
	Swing speed	rpm	13
	Gradeability	Degree(%)	35(70%)
	Ground pressure	Kgf/cm²	0.423
Working Range	Maximum digging radius	mm	8335
	Ground maximum digging radius	mm	8203
	Maximum digging depth	mm	5491
	Ground maximum digging depth	mm	5288
	Maximum vertical digging depth	mm	4826
	Maximum digging height	mm	8679
	Maximum dumping height	mm	6174
	Min. front turning radius	mm	2605
	Bucket digging force	kN	100
	Stick digging force	kN	68
Engine	Model		Cummins QSF3.8-C115
	Type		4-cylinder in-line, four-stroke turbocharger
	Emission		Tier III
	Displacement	L	3.76
	Rated power		86KW(115PS)@2220RPM
	Max. torque	N.m	470N.m@1400rpm
